| Fabric description | Remarks | |
|---|---|---|
| Yarn | Aramid | 1,000D ~ 3,000D Depends on requirement |
| Density (thread/in) |
9~30 | In case of Plain weave Depends on requirement |
| Weave | Plain, Leno | Depends on requirement |
| Width | 1,500 ~ 3,400mm | Depends on requirement |
| Test Sample | Ballistic Threat | Results(fps) | |||||||
|---|---|---|---|---|---|---|---|---|---|
| Sample Number |
Thickness (in.)(a) |
Weight (lbs.) |
Caliber | Obliquity | Shots Total /V50 |
Required V50 |
Test Result V50 |
High Partial |
Low Complete |
| NO. 1 | 0.249 | 1.42 | 22 FSP | 0° | 10/6 | NA | 2059 | 2067 | 2075 |
| Test Sample | Ballistic Threat | Results | ||||||
|---|---|---|---|---|---|---|---|---|
| Sample Number |
Thickness (in.)(a) |
Weight (lbs.) |
Caliber | Obliquity | Shots (b) | Max | Min | Penetrations |
| NO. 2 | 0.236 | 1.39 | 9mm | 0° | 5 | 1441 | 1408 | 0 |
